UL 61010-2-033 Ed. 2-2020

Standard for Safety Requirements for Electrical Equipment for Measurement, Control, and Laboratory Use - Part 2-033: Particular Requirements for Hand-Held Multimeters and Other Meters, for Domestic and Professional Use, Capable of Measuring Mains V - Published Date: January 10, 2020

1 Scope and object  This clause of Part 1 is applicable except as follows: 1.1.1 Equipment included in scope  Replacement:  Replace the existing text with the following:  This part of IEC 61010 specifies safety requirements for METERS.  The METERS that have a primary purpose of measuring voltage on a live MAINS CIRCUIT are within the scope of this standard. They have various names, but all of them have capability for measurements of voltages on a live MAINS CIRCUIT. Some of the names given to this equipment are as follows:   – MULTIMETER;   – digital MULTIMETER;   – VOLTMETER;   – clamp METER (see also Part 2-032).  For the purpose of this standard, the term METER is used for these HAND-HELD measuring instruments.  NOTE Parts of the equipment that are not within the scope of this Part 2-033 are considered to be covered by the requirements of Part 1 or other part 2's of IEC 61010 and then will also need to meet the requirements of these other parts. 1.1.2 Equipment excluded from scope  Addition:  Add the following new item to the list:  aa) IEC 61557 (Electrical safety in low voltage distribution systems up to 1 000 V a.c. and 1 500 V d.c. – Equipment for testing, measuring or monitoring of protective measures – Parts 1 through 12).  Addition:  Add the two following paragraphs at the end of the subclause:  Equipment that is not capable of measuring MAINS voltages is not within the scope of this Part 2-033. See IEC 61010-2-030 for requirements pertaining to such equipment.  Such equipment, including other HAND-HELD equipment such as oscilloscopes, wattmeters, process control MULTIMETERS, and communications test sets is not within the scope of this Part 2-033. 1.2.1 Aspects included in scope  Addition:  Add the following paragraph at the end of the subclause:  Requirements for protection against HAZARDS resulting from NORMAL USE and REASONABLY FORESEEABLE MISUSE of measuring circuits are given in Clause 101.
