ISO 23704-3:2023
General requirements for cyber-physically controlled smart machine tool systems (CPSMT) - Part 3: Reference architecture of CPSMT for additive manufacturing
This document specifies a reference architecture of cyber-physically controlled smart machine tool systems (CPSMT) for additive manufacturing (AM) based on the reference architecture of CPSMT as provided in ISO 23704-1 and the requirements for cyber-physically controlled smart additive manufacturing system.
The reference architecture of a CPSMT for AM includes:
— the technical requirements for the smart additive manufacturing system (SAMS),
— the reference architecture of the cyber-physically controlled machine tools (CPCM) for AM,
— the reference architecture of the cyber-supporting system for machine tools (CSSM) for AM, and
— the interface view of the CPSMT for AM.
This document also provides:
— stakeholder requirements for the SAMS,
— the concept of the digital thread,
— types of abnormality in AM, and
— use cases of reference architecture of a CPSMT for AM.
This document does not specify physical or implementation architecture.
