AGMA 929-A06

Calculation of Bevel Gear Top Land and Guidance on Cutter Edge Radius

This information sheet supplements ANSI/AGMA 2005--D03with calculations for bevel gear top land and guidance for selection of cutter edge radius for determination of tooth geometry. It integrates various publications with modifications to include face hobbing. It adds top land calculations for non--generated manufacturing methods. It is intended to provide assistance in completing the calculations requiring determination of top lands and cutter edge radii for gear capacity in accordance with ANSI/AGMA 2003--B97.
