Historical

AGMA 935-A05

Recommendations Relative to the Evaluation of Radial Composite Gear Double Flank Testers

The condition and alignment of gear measuring instruments can greatly influence the measurement of product gears. This information sheet provides qualification procedures for double flank testers that are used for the evaluation of radial composite deviations of gears. It discusses guidelines for alignment of double flank tester elements such as centers, ways, probe systems, etc. It also covers the application of artifacts to determine instrument accuracy. This information sheet is a supplement to standard ANSI/AGMA 2116-A05.

CONTENT PROVIDER
American Gear Manufacturers Association [agma]

Others Also Bought
Gear Classification and Inspection Handbook - Tolerances and Measuring Methods for Unassembled Spur and Helical ...
Inspection Practices - Part 1: Cylindrical Gears - Tangential Measurements
Accuracy Classification System - Tangential Measurements for Cylindrical Gears
Included in Packages
This standard is not included in any packages.
Document History
Revised By:
Amendments & Corrections
We have no amendments or corrections for this standard.
