ANSI/ASME B5.50-1994 (R2003)

V Flange Tool Shanks for Machining Centers with Automatic Tool Changers

This Standard pertains to the standardization of a basic tool holder shank and retention knob for numerically controlled machining centers with automatic tool changers. The requirements contained herein are intended to provide tool holder interchangeability between machining centers with automatic tool changers of various types. Dimensions for cone angle control are in accordance with the International Standard ISO-1947.
