Historical

ASME B18.29.1-2010

Helical Coil Screw Thread Inserts - Free Running and Screw Locking (Inch Series)

Delineates the dimensional data for the inch series helical coil screw thread inserts and the threaded holes into which they are installed. Both free-running and screw-locking types having unified fine and unified coarse thread series from size #1through 11/2 in. are covered. Appendices that describe insert selection, STI (screw thread insert) taps, gages and gaging, insert installation, and removal tooling are also included.

CONTENT PROVIDER
American Society of Mechanical Engineers [asme]

Others Also Bought
Helical Coil Screw Thread Inserts - Free Running and Screw Locking (Metric Series)
Gages and Gaging for Unified Screw Threads
Screw Threads, Metric Buttress - MJB Profile ( Reaffirmed: May 2006 )
Included in Packages
This standard is not included in any packages.
Document History
Amendments & Corrections
We have no amendments or corrections for this standard.
