DIN EN 558:2022

Industrial valves - Face-to-face and centre-to-face dimensions of metal valves for use in flanged pipe systems - PN and Class designated valves; German version EN 558:2022

This document (prEN 558:2020) has been prepared by Technical Committee CEN/TC 69 "Industrial valves", the secretariat of which is held by AFNOR. It specifies the "face-to-face" (FTF) and "centre-to-face" (CTF) dimensions for PN and Class designated metal valves used in flanged pipe systems.This European Standard covers valves with the following PN, Class and DN values:- PN 2,5; PN 6; PN 10; PN 16; PN 25; PN 40; PN 63; PN 100; PN 160; PN 250; PN 320; PN 400;- Class 125; Class 150; Class 250; Class 300; Class 600; Class 900; Class 1500; Class 2500;- DN 10; DN 15; DN 20; DN25; DN 32; DN 40; DN 50; DN 65; DN 80; DN 100; DN 125; DN 150; DN 200; DN 250; DN 300; DN 350; DN 400; DN 450; DN 500; DN 600; DN 700; DN 750; DN 800; DN 900; DN 1000; DN 1050; DN 1200; DN 1400; DN 1600; DN 1800; DN 2 000.For valves in other shell materials than metal the same FTF and CTF dimensions may be used.For relationship between DN and NPS see Annex B.
