IEEE C57.21-2021

IEEE Standard Requirements, Terminology, and Test Code for Shunt Reactors Rated Over 500 kVA

Revision Standard - Active. All liquid-immersed or dry-type, single-phase or three-phase, outdoor or indoor shunt reactors rated over 500 kVA are covered. Terminology and general requirements are stated, and the basis for rating shunt reactors is set forth. Routine, design, and other tests are described, and methods for performing them are given. Losses and impedance, temperature rise, dielectric tests, and insulation levels are covered. Construction requirements for liquid-immersed reactors and construction and installation requirements for dry-type reactors are presented. This standard also covers thyristor-controlled shunt reactors used in static var compensators.
