ISO 17396:2014

Synchronous belt drives - Metric pitch, trapezoidal profile systems T and AT, belts and pulleys

ISO 17396:2014 specifies the principal characteristics of synchronous endless and open belts and pulleys of the profile systems T and AT for use in synchronous belt drives for mechanical power transmission and where positive indexing or synchronization can be required.

The principal belt and pulley characteristics include

  • nominal belt tooth dimensions,
  • belt tooth pitch spacing,
  • belt length and width dimensions,
  • belt length measurement specifications,
  • pulley groove dimensions and tolerances,
  • pulley diameter and width dimensions and tolerances, and
  • pulley quality specification.
