ISO 18563-2:2017
Non-destructive testing - Characterization and verification of ultrasonic phased array equipment - Part 2: Probes
ISO 18563-2:2017 specifies the characterization tests performed at the end of the fabrication of a phased array probe. It defines both methodology and acceptance criteria.
ISO 18563-2:2017 is applicable to the following phased array probes used for ultrasonic non-destructive testing in contact technique (with or without a wedge) or in immersion technique, with centre frequencies in the range 0,5 MHz to 10 MHz:
a) non-matrix array probes:
- - linear;
- - encircling;
- - partial annular sectorial (type "daisy");
b) 2D-matrix array probes.
ISO 18563-2:2017 does not give methods and acceptance criteria to characterize the performance of an ultrasonic phased array instrument or the performance of a combined system. These are given in ISO 18563?1 and in ISO 18563?3.
