ISO 8177:2015

Aerospace - Omega clamps (saddle clamps) for fluid systems - Dimensions

ISO 8177:2015 specifies maximum and minimum dimensions for omega clamps (saddle clamps) installed by means of two bolts with nominal diameters of 5 mm.

The specified dimensions define a dimensional envelope. This International Standard shall not be considered as an inter-changeability standard. The tolerances for each type of clamp are to be defined in the parts standards drawings.

CONTENT PROVIDER
International Organization for Standardization [iso]

Included in Packages
This standard is not included in any packages.
Document History
Revises:
Revised By:
Amendments & Corrections
We have no amendments or corrections for this standard.
