MSS SP-45-2026

Drain and Bypass Connections

This Standard Practice establishes requirements for connections to valves and fittings to accommodate drains and bypasses in all pressure classes. Specific requirements contained in this Standard Practice include: a) Standard symbols and locations of openings for drains and bypasses; b) Standard sizes of drain and bypass openings; c) Minimum pipe thread lengths in drain and bypass tappings; d) Minimum diameter and depth of socket-weld connection for drains and bypasses; e) Butt-welding connections for drains and bypasses; f) Bosses for drain and bypass connections; g) Method for designating outlets of reducing fittings.

CONTENT PROVIDER
Manufacturers Standardization Society of the Valve and Fittings Industry, Inc. [mss]

Included in Packages
This standard is not included in any packages.
Document History
Revises:
Amendments & Corrections
We have no amendments or corrections for this standard.
