ANSI/AGMA 6035-A02 2025

Design, Rating and Application of Industrial Globoidal Wormgearing

This standard provides guidelines for the design, rating and application of globoidal wormgearing mounted at a 90 degree angle. Specific definitions for globoidal wormgearing terms are presented, along with formulas for determining the geometric sizes of the major features for the worm and gear. Design considerations, design procedures, gear blanks and self-locking conditions are also discussed. Procedures for rating the load capacity of globoidal wormgearing are included.

CONTENT PROVIDER
American Gear Manufacturers Association [agma]

Others Also Bought
Practice for Enclosed Cylindrical Wormgear Speed Reducers and Gearmotors
Included in Packages
This standard is not included in any packages.
Document History
Amendments & Corrections
We have no amendments or corrections for this standard.
